Eco Friendly Feature and Metal Frame Material 8 foot tall chain link fence

Product Categories
Anping Xinlong Wire Mesh Manufacture Co., Ltd.
Contact Now

Eco Friendly Feature and Metal Frame Material 8 foot tall chain link fence

Brand Name : Xinlong

Model Number : XLF-09

Certification : ISO9001:2008

Place of Origin : China

MOQ : 1000

Price : negotiate

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1000 per week

Delivery Time : 20 days

Packaging Details : Woven bag

Product name : Chain link fence

Material : Hot dipped galvanized

Wire diameter : 3.5mm

Mesh size : 60*60mm

Roll size : 1.5*15m

Packing : Woven bag

Contact Now

Eco Friendly Feature and Metal Frame Material 8 foot tall chain link fence

Eco Friendly Feature and Metal Frame Material 8 foot tall chain link fence

Dimension of Galvanized Chain Link Mesh
Mesh Wire Diameter Width Length
40mm×40mm 1.8mm-3.0mm 0.5m-4.0m 5m-25m
50mm×50mm 1.8mm-3.5mm 0.5m-4.0m 5m-25m
60mm×60mm 1.8mm-4.0mm 0.5m-4.0m 5m-25m
80mm×80mm 2.5mm-4.0mm 0.5m-4.0m 5m-25m
100mm×100mm 2.5mm-4.0mm 0.5m-4.0m 5m-25m
Dimension of PVC Coated Chain Link Mesh
Mesh Wire Diameter Width Length
40mm×40mm 2.8mm-3.8mm 0.5m-4.0m 5m-25m
50mm×50mm 3.0mm-5.0mm 0.5m-4.0m 5m-25m
60mm×60mm 3.0mm-5.0mm 0.5m-4.0m 5m-25m
80mm×80mm 3.0mm-5.0mm 0.5m-4.0m 5m-25m
100mm×100mm 3.0mm-5.0mm 0.5m-4.0m 5m-25m
Chain link fence surface treatment:
Surface treatment Min Max
Electro Galvanized 15g/m2 25g/m2
Hot dip galvanized 30g/m2 366g/m2
PVC/PE Coated 400microns 1000microns

Surface treatment of chain link fence

Galvanized: Electronic galvanized or hot dipped.

Zinc coat amount can according to customers' requirement.

PVC coated: 0.5mm thickness, color can be white,green,yellow,orange,black,grey or as request

Eco Friendly Feature and Metal Frame Material 8 foot tall chain link fence

Application:

Commercial grounds (Corporation, hotel, supermarket)
Private grounds (Courtyard)
Public grounds (Park, zoo, train or bus station, lawn)
Road and transit (Highway, railway or road city transit)
Used as fencing, decoration or protection for various facilities in industry, agriculture, infrastructure, transport, etc.
